Cisco ASR 1004 Hardware Installation Guide

DETAILED STEPS
Step 1
Before inserting a SIP, make sure that the chassis is grounded.
Step 2
To insert the SIP, carefully align the edges of the SIP between the upper and lower edges of the router slot.
Step 3
Carefully slide the SIP into the router slot until the SIP makes contact with the backplane.
Step 4
Tighten the locking thumbscrews on both sides of the SIP.
Step 5
Connect all cables to each SPA.
Removing a Shared Port Adapter from a SIP
To remove a shared port adapter (SPA), follow these steps.
SUMMARY STEPS
1.
Attach an ESD wrist strap between you and an unpainted chassis surface.
2.
Shut down the interface so that there is no traffic running through the shared port adapter when it is
removed.
3.
Disconnect all cables from the shared port adapter.
4.
Unscrew the captive installation screws on either side of the SPA.
5.
Grasp the handles and pull the SPA from the SIP.
DETAILED STEPS
Step 1
Attach an ESD wrist strap between you and an unpainted chassis surface.
Step 2
Shut down the interface so that there is no traffic running through the shared port adapter when it is removed.
Removing a shared port adapter while traffic is flowing through the ports can cause system disruption.Caution
Refer to the following example to shut down the interface FastEthernet0/1/0 on the 8-Port Fast Ethernet Shared Port
Adapter (SPA-8X1FE-TX-V2).
a) At the router# prompt, type:configure terminal and press Enter. The global configuration mode prompt Router
(config)# appears.
b) At the router (config)# prompt, type:interface FastEthernet0/1/0 and press Enter. The interface configuration mode
prompt Router(config-if)# appears.
c) At the router (config-if)# prompt, type:shutdown and press Enter. This disables the interface FastEthernet0/1/0.
d) At the router(config-if)# prompt, type:end and press Enter. The privileged EXEC mode prompt Router# appears.
Step 3
Disconnect all cables from the shared port adapter.
Step 4
Unscrew the captive installation screws on either side of the SPA.
Step 5
Grasp the handles and pull the SPA from the SIP.
Cisco ASR 1000 Series Router Hardware Installation Guide
537
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing a Shared Port Adapter from a SIP

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
