Cisco ASR 1004 Hardware Installation Guide

DescriptionComponent
Front and rear chassis rack-mount brackets that you
will attach to the chassis with the respective screws
Accessories Kit
You must order the Accessories Kit
separately if you order the Cisco ASR
1009-X Router or Cisco ASR 1006-X Router
chassis as a spare.
Note
Three sets of screws, one set for:
•
Front rack-mount brackets (use the black
screws)
•
Rear rack-mount brackets (use the package with
the 5 screws)
•
Cable-management brackets (use the package
with the 4 screws)
Two cable-management brackets with U-feature
design devices attached, with a different size for each
chassis.
1 RJ-45 to RJ-45 crossover cable
1 RJ-45 to DB-9 (female) adapter
One disposable wrist strapESD, Wrist Strap (disposable)
Regulatory Compliance and Safety Information for
the Cisco ASR 1000 Series Aggregation Services
Routers at http://www.cisco.com/c/en/us/td/docs/
routers/asr1000/rcsi/asr1rcsi.html.
Documentation
Power cord if an AC power supply was shipped.
There are none for the DC power supply units.
Optional Equipment
Most Cisco documentation is online or on the Cisco Documentation DVD. Documentation that ships with
your Cisco ASR 1000 Series Router includes the Regulatory Compliance and Safety Information for the
Cisco ASR 1000 Series Aggregation Services Routers document, and the Documentation Roadmap for
Cisco ASR 1000 Series, which provides links and information for the Cisco ASR 1000 Series Aggregation
Services Routers documentation.
Note
Cisco ASR 1000 Series Router Installation Checklist
To assist you with your installation and to provide a historical record of what was done by whom, photocopy
the Cisco ASR 1000 Series Router Installation Checklist shown in the following table. Use this to record
when each procedure or verification is completed. When the checklist is completed, place it in your site log
along with the other records for your new router.
Cisco ASR 1000 Series Router Hardware Installation Guide
136
Preparing Your Site for Installation
Cisco ASR 1000 Series Router Installation Checklist

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
