Cisco ASR 1004 Hardware Installation Guide

Warning Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning This unit is intended for installation in restricted access areas. A restricted access area can be accessed
only through the use of a special tool, lock and key, or other means of security. Use when a product has an
accessible HAZ/V circuits or a DC supply that is not provided with a field wiring cover. Statement 1017
Related Documentation
Your Cisco ASR 1000 Series Routers and the Cisco IOS software running on it contain extensive features
and functionality, which are documented in the following resources:
•
All documentation related to the Cisco ASR 1000 Series Routers is listed in the online Cisco ASR 1000
Series Aggregation Services Routers Documentation Roadmap . Information in this master index includes
troubleshooting tools and documentation, regulatory compliance and safety information, and installation
and replacement information. Also see the Cisco ASR 1000 Series Port Adapter Documentation Roadmap
for specific shared port adapters supported on the Cisco ASR 1000 Series Routers.
Some of the Cisco ASR 1000 Series Routers documentation that is listed on the Cisco ASR 1000 Series
Aggregation Services Routers Documentation Roadmap includes:
•
Quick Start Guides for the Cisco ASR 1000 Series Routers. These guides provide quick reference
information about chassis or parts installation procedures.
◦
Cisco ASR 1000 Series Router Hardware Installation Guide
xxxiii
Preface
Related Documentation

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
