Power Supply Requirements for All Cisco ASR 1000 Series Routers
This section contains power supply specifications for all Cisco ASR 1000 Series Routers. The following topics
are covered:
•
DC power supply input ratings and circuit breaker specifications
◦
Maximum and minimum Amps for the branch circuit breakers
◦
Maximum and minimum size of the AWG wire required for each circuit breaker.
•
AC and DC power supply types
•
AC and DC power supply ratings
DC Power System Input Requirements for Cisco ASR 1000 Series Routers
The DC power supply for the Cisco ASR 1006, Cisco ASR 1004, Cisco ASR 100, Cisco ASR 1013, and Cisco
ASR 1001 routers operate at individual specifications.
The following table shows the common input ranges and circuit breaker requirements.
Table 14: Cisco ASR 1000 Series Router DC Power Supply System Input Requirements
AWG # WireCircuit Breaker
Amps
System Input
Rating (Amps)
Cisco ASR 1000
Series Router
DC Power
Supply
MaximumMinimumMaximumMinimum
Always AWG
#6 wire
Always 5040Cisco ASR 1006
810403024Cisco ASR 1004
Cisco ASR
1002:
• –48 VDC
•
+24 VDC
1012302016
88404032
Always AWG
#6 wire
Always 5040Cisco ASR 1013
1010302014Cisco ASR 1001
Cisco ASR 1000 Series Router Hardware Installation Guide
49
Cisco ASR 1000 Series Routers Component Overview
Power Supply Requirements for All Cisco ASR 1000 Series Routers

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
