Cisco ASR 1004 Hardware Installation Guide

This product can be installed in a network telecommunication facility or location where the NEC applies.
An electrical conducting path shall exist between the product chassis and the metal surface of the enclosure
or rack in which it is mounted or to a grounding conductor. Electrical continuity shall be provided by using
thread-forming type mounting screws that remove any paint or nonconductive coatings and establish a
metal-to-metal contact. Any paint or other nonconductive coatings shall be removed on the surfaces between
the mounting hardware and the enclosure or rack. The surfaces shall be cleaned and an antioxidant applied
before installation.
The grounding architecture of this product is DC-isolated (DC-I).
DC-powered products have a nominal operating DC voltage of 48 VDC. Minimal steady state DC operating
voltage is 40.5 VDC. Reference American National Standards Institute (ANSI) T1.315, Table 1.
Standard Warning Statements
This section describes the warning definition and then lists core safety warnings grouped by topic.
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you
work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with
standard practices for preventing accidents. Use the statement number provided at the end of each warning
to locate its translation in the translated safety warnings that accompanied this device.
Note: SAVE THESE INSTRUCTIONS Statement 1071
Warning
General Safety Warnings
Read the installation instructions before you connect the system to its power source. Statement 1004Warning
Ultimate disposal of this product should be handled according to all national laws and regulations. Statement
1040
Warning
No user-serviceable parts inside Do not open. Statement 1040Warning
Installation of the equipment must comply with local and national electrical codes. Statement 1074Warning
To comply with the Class A emissions requirements shielded twisted pair T1/E1 cables must be used for
SPA-8-Port Channelized T1/E1 SPA (SPA-8XCHT1/E1) on the Cisco ASR 1006, ASR 1004, and ASR
1002. EN55022/CISPR22 Statement
Warning
Cisco ASR 1000 Series Router Hardware Installation Guide
115
Preparing Your Site for Installation
Standard Warning Statements

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
