already installed in the rack do not impair access to the cards or require you to disconnect cables
unnecessarily to perform equipment maintenance or upgrades
.
•
Install rack stabilizers (if available) before you mount the chassis
.
•
Provide an adequate chassis ground (earth) connection for your router chassis.
In addition to the preceding guidelines, review the precautions for avoiding excessive temperature conditions
in the “Site Environmental Requirements” section on page 5-9 .
The following table provides the Cisco ASR 1002-F Router dimensions and weight information.
Table 67: Cisco ASR 1002-F Router Dimensions and Weight
DimensionsCisco ASR 1002-F
22.50 in. (57.15 cm)(including card handles,
cable-management brackets, power supply handles
Depth
3.47 in. (8.813 cm)—2RU rack-mount per EIA
RS-310 standard
Height
17.25 in. (43.815 cm)—19-inch rack-mount
Width
40 lb (18.143 k)—fully configured
Weight
Guidelines for an Equipment Shelf or Tabletop Installation
The chassis should already be in the area where you will install it. If you have not determined where to install
your chassis, see the “Cisco ASR 1000 Series Routers Component Overview” section on page 2-1 for
information about site considerations.
If you are not rack-mounting your Cisco ASR 1000 series chassis, place it on a sturdy equipment shelf or
tabletop.
When installing the Cisco ASR 1002-F Router on an equipment shelf or tabletop, ensure that the surface is
clean and that you have considered the following:
•
The Cisco ASR 1002-F Router requires at least 3 inches (7.62 cm) of clearance at the inlet and exhaust
vents (the front and rear sides of the chassis).
•
The Cisco ASR 1002-F Router should be installed off the floor. Dust that accumulates on the floor is
drawn into the interior of the router by the cooling fans. Excessive dust inside the router can cause
overtemperature conditions and component failures
.
•
There must be approximately 19 inches (48.3 cm) of clearance at the front and rear of the chassis to
install and replace FRUs, or to access network cables and equipment.
Cisco ASR 1000 Series Router Hardware Installation Guide
288
Cisco ASR 1002-F Router Overview and Installation
Guidelines for an Equipment Shelf or Tabletop Installation
