SPA slot 33
The Cisco ASR 1002-X Router has an integrated ESP which is not field upgradeable. Depending on the Cisco
optional software license that is installed, the ESP forwarding bandwidth can be software field upgraded from
the default bandwidth of 5 Gbps to 10 Gbps, 20 Gbps, or 36 Gbps. For more information about the software
license, see the Cisco ASR 1000 Series Aggregation Services Routers Release Notes at: http://www.cisco.com/
en/US/docs/routers/asr1000/release/notes/asr1k_rn_rel_notes.html
The following table describes the LEDs on the integrated ESP.
Table 69: Integrated ESP LEDs
Behavior in the
Power-Up State
ColorLEDLED LabelNo.
All the power supplies
are within operational
limits.
Solid greenPowerPWR1
Off. The router is in
standby mode.
Off
The ESP is green when
active.
GreenActiveACTV2
Code has successfully
downloaded, and is
operational.
GreenSTATUSSTAT3
Boot ROM has
successfully loaded.
Yellow
Not booted.Red
Will always be off.NoneStandbySTBY4
Power Supplies in the Cisco ASR 1002-X Router
The Cisco ASR 1002-X Router power supply module supports the following Cisco power supplies:
•
AC power supply operates between 85 V ac to 264 V ac
• –48 V DC power supply operates between –40.5 V dc and –72 V dc
•
+24 V DC power supply operates between 21 V dc and 36 V dc
The power supplies are installed in the rear of the chassis and are hot pluggable. The Cisco ASR 1002-X
Router supports up to 588 W input power from an infrastructure standpoint (cooling capacity, midplane, and
power distribution), but the initial power supply development limit is up to 470 W output (AC and DC input).
Cisco ASR 1000 Series Router Hardware Installation Guide
322
Cisco ASR 1002-X Router Overview and Installation
Power Supplies in the Cisco ASR 1002-X Router
