Cisco ASR 1004 Hardware Installation Guide

DescriptionColorLEDLED Label
When the LED is off, it
signals that the –48 VDC
output voltage are within
the normal operating
range. Output voltage
between the minimum
and maximum limits will
not create an output fail
alarm, and output
voltages below the
minimum or above the
maximum will create an
Output Fail alarm.
When you turn the power
supply on, the red LED
illuminates for two to
three seconds to test LED
operation before going
off.
RedPower supply activityOUTPUT FAIL
AC/DC Power System Output for Cisco ASR 1006
The power supply output tolerance is defined in the following table under all combinations of line variation.
Total system consumption per power supply should not exceed 1200 W.
Table 19: Cisco ASR 1006 Router Power System Output Voltage and Current
+3.3 V+12 VDCOutput Voltage
3.20 VDC11.80 VDCMinimum
3.30 VDC12.00 VDCNominal
3.40 VDC12.20 VDCMaximum
Output Current
0.10 A2.80 AMinimum
3.125 A101.7 AMaximum
Cisco ASR 1000 Series Router Hardware Installation Guide
58
Cisco ASR 1000 Series Routers Component Overview
AC/DC Power System Output for Cisco ASR 1006

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
