Captive screws7DB-25 alarm connector2
Power supply handle8Tie-wrap tabs3
Power supply On (|) /Off
(O) switch
9Terminal and plastic
cover
4
Power supply LEDs10Grounding symbol5
The following table describes the power supply LEDs and connectors on the rear of the chassis.
Table 18: Cisco ASR 1006 Router – 48 VDC Power Supply LEDs
DescriptionColorLEDLED Label
LED illuminates green to
signal that the –48 VDC
power supply input
voltage is greater
than–43.5VDC at turn-on
and remains green down
to –39VDC.
GreenA bi-color LED indicates
presence of input voltage
INPUT OK
The LED illuminates
amber when the input
voltage (falls below
–39VDC) and indicates
that there is still a voltage
present (voltage on the
terminal block). The LED
remains amber and is
active to around 20 V
+/-5 V. The LED is not
illuminated if the input is
below –15 V.
Amber
The LED illuminates s
green when all fans are
operational.
GreenA bi-color LED indicates
power supply fan status
FAN OK
The LED illuminates red
when a fan failure is
detected.
Red
Cisco ASR 1000 Series Router Hardware Installation Guide
57
Cisco ASR 1000 Series Routers Component Overview
–48 VDC Power Supply LEDs and Connectors for Cisco ASR 1006
