Cisco ASR 1004 Hardware Installation Guide

Four-Post Rack Installation
The Cisco ASR 1004 Router can be flush-mounted in a 19-inch equipment rack using the rack-mounting kit
provided with your system. The Cisco ASR 1004 Router can be mounted into the rack using two recommended
methods:
•
Installing the chassis in an existing rack with equipment.
•
Installing an empty chassis in a rack with no equipment installed.
When handling the chassis, always follow proper lifting practices. See the “Chassis-Lifting Guidelines” section.
Inner clearance (the width between the inner sides of the two posts or rails) must be at least 19 inches
(48.26cm). The height of the chassis is 6.95 inches (17.653 cm). Airflow through the chassis is from front
to back.
Note
Make sure the rack is stabilized.Note
SUMMARY STEPS
1.
(Optional) Install a shelf in the rack to support the Cisco ASR 1004 Router. If you are using a shelf then
raise the chassis to the level of the shelf. Let the bottom of the chassis rest on the brackets, but continue
to support the chassis.Using two people, lift the chassis into the rack using the side handles and grasping
underneath the power supply bays.
2.
Position the chassis until the rack-mounting flanges are flush against the mounting rails on the rack.
3.
Hold the chassis in position against the mounting rails while the second person finger-tightens a screw to
the rack rails on each side of the chassis. The following image shows the rear rack-mount brackets and
the front rack-mount brackets on the Cisco ASR 1004 Router.
4.
Finger-tighten 4 more screws to the rack rails on each side of the chassis.
5.
Tighten all screws on each side to secure the chassis to the equipment rack.
6.
Use a level to verify that the tops of the two brackets are level, or use a measuring tape to verify that both
brackets are the same distance from the top of the rack rails.
DETAILED STEPS
Step 1
(Optional) Install a shelf in the rack to support the Cisco ASR 1004 Router. If you are using a shelf then raise the chassis
to the level of the shelf. Let the bottom of the chassis rest on the brackets, but continue to support the chassis.Using two
people, lift the chassis into the rack using the side handles and grasping underneath the power supply bays.
Step 2
Position the chassis until the rack-mounting flanges are flush against the mounting rails on the rack.
Use the third hole up from the bottom of the rack-mount bracket and the third hole down from the top of the
rack-mount bracket.
Note
Cisco ASR 1000 Series Router Hardware Installation Guide
199
Cisco ASR 1004 Router Overview and Installation
Four-Post Rack Installation

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
