Cisco ASR 1004 Hardware Installation Guide

Table 131: RJ-45 Management Ethernet Port Pinouts
DescriptionDirectionSignalPin
Bidirectional DataBiBi Data A+1
Bidirectional DataBi
Bi Data A–
2
Bidirectional DataBiBi Data B+3
Bidirectional DataBiBi Data C+4
Bidirectional DataBi
Bi Data C–
5
Bidirectional DataBi
Bi Data B–
6
Bidirectional DataBiBi Data D+7
Bidirectional DataBi
Bi Data D–
8
BITS/DTI Interface Port Signals and Pinouts
The following table lists the pinouts of the front panel BITS/DTI RJ45 port.
Table 132: BITS/DTI RJ-45 Receptacle Pinouts for Cisco ASR1000-RP2
DescriptionDirectionSignalPin
Receive
Ring/Bidirectional (DTI)
Input/Bi (DTI)RX Ring1
Receive TIP
(T1/E1)/Bidirectional
(DTI)
Input/Bi (DTI)RX TIP2
——
N/C3, 4
Transmit Ring / unused
for DTI
OutputTX Ring5
Transmit TIP/ unused for
DTI
OutputTX TIP6
——
N/C7,8
Cisco ASR 1000 Series Router Hardware Installation Guide
640
Cisco ASR 1000 Series Router Route Processor and Embedded Services Processor Signals and Pinouts
BITS/DTI Interface Port Signals and Pinouts

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
