Power Supplies in the Cisco ASR 1002-F Router
The Cisco ASR 1002-F Router power supply consists of either an AC or DC input in a closed frame power
supply with two DC voltage outputs: 12 V and 3.3 V. The AC power supply operates between 85 VAC to
264 VAC and the DC power supply operates between –40.5 VDC to –72 VDC.
The power supplies are installed into the rear of the chassis and are hot pluggable. The Cisco ASR 1002-F
Router supports up to 588 W of input power from an infrastructure standpoint, but the initial power supply
development limit is up to 470 W of output power (AC and DC input).
AC Power Supply for the Cisco ASR 1002-F Router
The AC power supply input inlet is an IEC connector with an AC switch and the current rating on the connector
and switch is 10 A. The AC power supply is secured into the chassis with two captive installation screws
mounted on the faceplate.
The following table describes the LEDs on the Cisco ASR 1002-F Router.
Table 63: Cisco ASR 1002-F Router AC Power Supply LEDs
DescriptionColorLEDLED Label
The AC input voltage is greater
than 85V.
GreenPower supply activityINPUT OK
If the LED is not illuminated,
then either the input voltage is
less than 70V, or the power
supply is turned off.
If the AC input voltage is
between 70V and 85V, the
INPUT OK LED can be on, off,
or flashing.
None
All fans are operational.GreenPower supply fan activity
A bi-color LED indicates fan
status.
FAN OK
A fan failure is detected.Red
Cisco ASR 1000 Series Router Hardware Installation Guide
283
Cisco ASR 1002-F Router Overview and Installation
Power Supplies in the Cisco ASR 1002-F Router

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
