Cisco ASR 1004 Hardware Installation Guide

SUMMARY STEPS
1.
Carefully slide the internal hard drive unit into the Cisco ASR1000-RP2 faceplate slot. The component is
keyed for easy insertion.
2.
Tighten the fastener screw on the front panel.
3.
Wait until the following console message is displayed:
4.
Verify the disk is working by running: dir harddisk
DETAILED STEPS
Step 1
Carefully slide the internal hard drive unit into the Cisco ASR1000-RP2 faceplate slot. The component is keyed for easy
insertion.
Step 2
Tighten the fastener screw on the front panel.
Step 3
Wait until the following console message is displayed:
Example:
%IOSXE-0-PLATFORM: R0/0: udev: harddisk: file system ready” appears.
If, after several minutes, the above message is not displayed, run:
request platform hardware filesystem harddisk: online
The only reason the system would not be able to automatically mount the new hard disk following a physical
insertion is if the disk is not partitioned correctly.
Note
Step 4
Verify the disk is working by running: dir harddisk
What to Do Next
You have completed the steps required to replace the Cisco ASR1000-RP2 internal hard drive.
Removing and Replacing the Hard Drive on the Cisco ASR 1002-X
Router
The Cisco ASR 1002-X Router supports an optional removable hard drive. This section explains how to
remove and replace this hard drive.
During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly
touch the backplane with your hand or any metal tool, or you could shock yourself. Statement 94
Warning
Before you begin, read the following important notices:
•
The hard drive is accessible from the front panel of the router and supports the online insertion and
removal feature (OIR) using the following CLI commands:
◦
request platform hardware filesystem harddisk: offline (unmounts the hard disk)
◦
request platform hardware filesystem harddisk: online (mounts the hard disk.)
Cisco ASR 1000 Series Router Hardware Installation Guide
487
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing the Hard Drive on the Cisco ASR 1002-X Router

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
