Cisco ASR 1004 Hardware Installation Guide

SUMMARY STEPS
1.
Insert an AC power supply in power supply slot 0 or power supply slot 1 until it is fully seated.
2.
Tighten the captive screws.
3.
Insert the AC power cable.
4.
Plug the power supply cable into the power source.
5.
Turn the power supply Standby switch to the On (|) position.
DETAILED STEPS
Step 1
Insert an AC power supply in power supply slot 0 or power supply slot 1 until it is fully seated.
Step 2
Tighten the captive screws.
Step 3
Insert the AC power cable.
Step 4
Plug the power supply cable into the power source.
Step 5
Turn the power supply Standby switch to the On (|) position.
What to Do Next
This completes the procedure for installing the AC power supply in the Cisco ASR 1013 Router.
Removing and Replacing a DC Power Supply in Cisco ASR 1013 Router
This section provides information about removing and installing a DC power supply in the Cisco ASR 1013
Router.
When you install the unit, the ground connection must always be made first and disconnected last. Statement
1046
Warning
Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Statement 1003
Warning
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning
Installation of the equipment must comply with local and national electrical codes. Statement 1074Warning
Cisco ASR 1000 Series Router Hardware Installation Guide
590
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing a DC Power Supply in Cisco ASR 1013 Router

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
