+24 VDC Power System Input for the Cisco ASR 1002-X Router
The +24 VDC power supply operates within specification between +21 VDC and +36 VDC continuously
after the power supply DC input is turned on. The power supply measures the input voltage at the power
supply terminals and turns off the supply when the input voltage reaches 19.0 V +/- 0.5 V when this low
voltage threshold is reached, the power supply does not resume operation until the input voltage reaches 20.0
V +/- 0.5 V. When the turn-on threshold of 20 V is reached, then the +24 VDC power supply meets all
specification requirements down to the low voltage threshold of 19 V (+/- tolerance).
+24 VDC Power System Output for the Cisco ASR 1002-X Router
The +24 VDC power supply output tolerance is defined in the following table, under all combinations of +24
VDC input line variation. The total system power consumption should not exceed 470 W or output rating of
each power supply.
Two power supplies are used for the redundant operation. The system’s total power consumption should
not exceed the rating of one power supply to maintain redundancy.
Note
Table 74: Cisco ASR 1002-X Router +24 VDC Power System Output Voltage and Current
+3.3 V+12 VDCOutput Voltage
3.20 V11.80 VDCMinimum
3.30 V12.00 VDCNominal
3.40 V12.20 VDCMaximum
Output Current
0.10 A2.0 AMinimum
3.125 A39 AMaximum
Any combination of output voltage and current cannot exceed the total power rating of 470 W.Note
The following are the important notes regarding the +24 VDC power supply in the Cisco ASR 1002-X Router:
• Output Voltage Alarm Threshold—The Output Voltage Alarm is raised when the output voltage is below
the low end of the minimum limit or above the high end of the maximum limit (as shown in the following
table). When the output voltage is above the high end of the minimum limit or below the low end of the
maximum limit, the LED does not turn to red.
Cisco ASR 1000 Series Router Hardware Installation Guide
329
Cisco ASR 1002-X Router Overview and Installation
Power Supplies in the Cisco ASR 1002-X Router

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
