Hardware Requiring a CPLD Upgrade
For details about Cisco ASR 1000 hardware configuration combinations that require a CPLD field
programmable upgrade for components to be supported in IOS XE Release 3.1S, see Upgrading Field
Programmable Hardware Devices for Cisco ASR 1000 Series Routers .
Incompatible Hardware Configuration Combinations
The following table lists ASR 1000 hardware configuration combinations that are not compatible from Cisco
IOS XE Release 3.1S onward.
Table 7: Incompatible Cisco Hardware Configuration Combinations from IOS XE Release 3.1S Onward
ResultASR1000-SIPASR1000-ESPASR1000-RPChassis
ESP-20 disabled
ESP-40 disabled
ESP-100 disabled
NA (built in)ESP-20
ESP-40
ESP-100
NA (built in)Cisco ASR 1002
Router
ESP-5 disabled
ESP-100 disabled
—
ESP-5
ESP-100
—
Cisco ASR 1004
Router
ESP-5 disabled
—
ESP-5
—
Cisco ASR 1006
Router
RP1 disabled
——
RP1Cisco ASR 1013
Router
—
NA (built in)Integrated
embedded services
processor
NA (built in)Cisco ASR 1001
Router
—
NA (built in)Integrated
embedded services
processor
NA (built in)Cisco ASR 1002-X
Router
Incompatible ASR1000-ESP Error Message
This section describes what happens when an incompatible Cisco ASR1000-ESP is inserted into the following
Cisco ASR 1000 series router:
•
Cisco ASR1000-ESP20 is inserted into Cisco ASR 1002 Router
•
Cisco ASR1000-ESP40 is inserted into Cisco ASR 1002 Router
•
Cisco ASR1000-ESP100 is inserted into Cisco ASR 1002 Router
•
Cisco ASR1000-ESP5 or Cisco ASR1000-ESP100 is inserted into Cisco ASR 1004 Router or ASR 1006
Router
Cisco ASR 1000 Series Router Hardware Installation Guide
30
Cisco ASR 1000 Series Routers Component Overview
Cisco ASR 1000 Series Hardware Configuration Combinations

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
