Cisco ASR 1004 Hardware Installation Guide

The following image shows the Cisco ASR 1002-F Router faceplate labels for the Cisco integrated RP and
Cisco ASR 1002-ESP-F.
Figure 119: Cisco Integrated RP and Cisco ASR 1002-ESP-F LEDs on Cisco ASR 1002-F Router
Cisco ASR 1002-ESP-F
LEDs: PWR, STAT,
ACTV, STBY
2Cisco RP LEDs: PWR,
STAT, MIN, MAJ, CRIT
1
The following image shows the Cisco ASR 1002-F Router faceplate labels for the Cisco integrated RP.
Figure 120: Cisco Integrated RP Faceplate Labels
CON6Gigabit Ethernet ports 0,
1, 2, 3
1
Cisco ASR 1000 Series Router Hardware Installation Guide
280
Cisco ASR 1002-F Router Overview and Installation
Cisco Integrated RP and Cisco ASR 1002-ESP-F Description
