Cisco ASR 1004 Hardware Installation Guide

Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Statement 1003
Danger
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning
This section provides the procedures for connecting AC-input and DC input power to your Cisco ASR 1002-F
Router.
The DC power supply for the Cisco ASR 1006, Cisco ASR 1004, Cisco ASR 1002, and Cisco ASR 1002-F
routers operate at individual specifications. The following table shows the common input ranges and circuit
breaker requirements.
Table 68: Cisco ASR 1000 Series Router DC Power Supply System Input Requirements
AWG # WireCircuit Breaker
Amps
System Input
Rating (Amps)
Cisco ASR 1000
Series Router
DC Power
Supply
MaximumMinimumMaximumMinimum
Always AWG
#6 wire
Always 5040Cisco ASR 1006
810403024Cisco ASR 1004
1012302016Cisco ASR 1002
and Cisco ASR
1002-F 1
1 The Cisco
ASR 1002-F
Router DC
power supply,
with 16 A input
rating must use
an AWG #12
gauge wire for a
20 A circuit
breaker and an
AWG #10 gauge
wire for a 30 A
circuit breaker.
Cisco ASR 1000 Series Router Hardware Installation Guide
307
Cisco ASR 1002-F Router Overview and Installation
Connecting Power to the Cisco ASR 1002-F Router

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
