Cisco ASR 1004 Hardware Installation Guide

•
Online insertion and removal (OIR) capability
•
Route processor and embedded services processor redundancy in the Cisco ASR 1000 Series Routers
(Cisco ASR 1013 Router and Cisco ASR 1006 Router)
•
Control processor for ASR 1000 Series SPA Interface Processor
•
Control processor for embedded services processors (Cisco ASR1000-ESP5, Cisco ASR1000-ESP10,
Cisco ASR1000-ESP20, integrated Cisco ASR1002-ESP-F, Cisco ASR1000-ESP40, Cisco
ASR1000-ESP100, and Cisco ASR1000-ESP200)
•
10 Gbps and 20 Gbps interconnect between Cisco QuantumFlow Processor with redundant Cisco ASR
1000 Series ESP to mirror data for stateful features
•
Power supply redundancy
•
Environmental monitoring and reporting functions
•
Family of routers using common hardware and software architecture
•
Centralized forwarding design (all network traffic passes through one engine)
• Front-to-back airflow—Allows you to mount the router from either front or back into 19-inch equipment
rack
•
Supports half-height shared port adapters (HHSPAs) and full-height shared port adapters (FHSPAs)
The Cisco ASR 1001 Router does not support full-height SPAs.Note
•
Single midplane design (all connectors on one interface midplane)
• One 10/100/1000-Mbps Ethernet Management port—To be used only as a management port; not to be
used as an Ethernet interface port
•
Both quarter-rate (87.5 MHz) and full-rate (350 MHz) shared port adapter operation
The Cisco QuantumFlow Processor processing provides:
•
Architecture to address Cisco ASR 1000 Series router performance, cost, power, and feature velocity
•
Next Generation forwarding and queuing subsystems for Cisco routers to provide data path acceleration.
The Cisco ASR 1000 Series route processor system performs the following system management functions:
•
Sending and receiving routing protocol updates
•
Managing tables, caches, and buffers
•
Monitoring interface and environmental status
•
Providing Simple Network Management Protocol (SNMP) management through the console and Telnet
interface
•
Accounting for and switching of data traffic
•
Booting and reloading images
Cisco ASR 1000 Series Router Hardware Installation Guide
4
Cisco ASR 1000 Series Routers Hardware Overview
Cisco ASR 1000 Series Router Features

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
