Cisco ASR 1004 Hardware Installation Guide

USB0 and USB1
connectors
4Internal hard drive LED1
Cisco ASR 1000 Series
RP LEDs
5External USB Flash LED2
——
Internal USB bootflash
LED
3
Do not remove a USB Flash memory module when issuing some file access command or a read/write
operation to the Flash memory module when it is processing. The router might reload or the USB Flash
memory module can be damaged. You can check to see if the USB activity LED on the Cisco ASR1000-RP
front panel is flashing, prior to the removal of the USB device
Caution
To remove and then replace a USB 1 GB flash token memory stick from a Cisco ASR1000-RP, follow these
steps:
SUMMARY STEPS
1.
Pull the memory stick from the USB port.
2.
To replace a Cisco USB Flash memory stick, simply insert the module into the USB port 0 or 1 port as
shown in the following figure. The Flash memory module can be inserted only in one way, and can be
inserted or removed regardless of whether the router is powered up or not.
DETAILED STEPS
Step 1
Pull the memory stick from the USB port.
The Cisco ASR 1002 Router has only one USB
port.
Note
Step 2
To replace a Cisco USB Flash memory stick, simply insert the module into the USB port 0 or 1 port as shown in the
following figure. The Flash memory module can be inserted only in one way, and can be inserted or removed regardless
of whether the router is powered up or not.
Cisco ASR 1000 Series Router Hardware Installation Guide
528
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing Cisco ASR 1000 Series Router 1 GB USB Flash Token Memory Stick

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
