Cisco ASR 1004 Hardware Installation Guide

a) Leave a small service loop in the AC power cord from the inlet and then secure the power cord through the AC power
supply handle as shown in the following figure. Alternatively, go to step 3b.
Figure 278: Cisco ASR 1002 Router AC Power Supply and Cord in Slot 1
AC power cord1
b) Take the power cord and run it below the handles of the power supply in slot 1and the power supply in slot 0 (left).
Make sure the power cord is hanging loosely so that it cannot be disconnected from the AC power inlet (see the
following figure).
Figure 279: Cisco ASR 1002 Router AC Power Cord Through AC Power Supply 0 and 1
Cisco ASR 1000 Series Router Hardware Installation Guide
569
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing an AC Power Supply in Cisco ASR 1002 Router
