CDM-625 Advanced Satellite Modem Revision 13

IP Packet Processor Option MN-CDM625

18–14

Step

Task

Plug the f ront p anel r ibbon c able back i nto its mating

connector on the modem’s framing board.

Use the screwdriver t o reinstall t he t op cover o nto the

CDM-625 chassis with its existing mounting hardware.

Plug the modem’s power cord back into its power source.

The CDM-625 IP Packet Processor upgrade is now complete and you may turn on and resume use of the modem.
