Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to
Query
Retrieve
next 5
unread New
Stored
Statistics
N/A
180 bytes
Query only.
Unit returns the oldest 5 Stored Statistics (including newly added Minimum and Average Receive Signal level),
which have not yet been read over the remote control in the reply form [CR]sub-body[CR]sub-body[CR]
sub-body[CR]sub-body[CR]sub-body, where sub-body = AA.ABB.BC.CD.DEE.E,FF.Fddmmyyhhmmss:
AA.A=Minimum Eb/No during sample period.
BB.B=Average Eb/No during sample period.
C.C=Max. Tx Power Level Increase during sample period.
D.D=Average Tx Power Level Increase during sample period.
EE.E=Negative value of Minimum Receive Signal Level in dB during sample period.
FF.F=Negative value of Average Receive Signal Level in dB during sample period.
ddmmyy = date stamp.
hhmmss = time stamp.
If there are no new events, the unit replies with RNN*. If there are less than 5 statistics to be retrieved, the
remaining positions are padded with zeros.
Note: RNN includes all information provided in RNS, plus Rx Signal level. Do not mix use of RNS and
RNN.
N/A
RNN?
RNN=[CR]AA.ABB.
BC.CD.DEE.E,FF.F
ddmmyyhhmmss[C
R]AA.ABB.BC.CD.D
EE.E,FF.Fddmmyyh
hmmss[CR]AA.ABB.
BC.CD.DEE.E,FF.F
ddmmyyhhmmss[C
R]AA.ABB.BC.CD.D
EE.E,FF.Fddmmyyh
hmmss[CR]AA.ABB.
BC.CD.DEE.E,FF.F
ddmmyyhhmmss
(see Description of
Arguments)
Clear All
Stored
Statistics
CAS=
None
Command only.
Forces the software to clear the software statistics log.
Example: CAS=
Note: This command takes no arguments.
CAS=
CAS?
CAS*
CAS#
N/A
N/A
Initialize
Statistics
Pointer
ISP=
None
Command only.
Resets internal pointer to allow RNS? queries to start at the beginning of the statistics log.
ISP=
ISP#
N/A
N/A
Force 1:1
Switch
FSW=
None
Command only.
Forces unit to toggle Unit Fail relay to “fail” state for approx 500ms. If unit is part of a 1:1 pair and is currently
the ‘Online’ unit, this will force a switchover, so unit will then be in ‘Standby’ mode. The command is always
executed by the unit, regardless of whether it is standalone, in a 1:1 pair, or part of a 1:N system.
Note: This command takes no arguments.
FSW=
FSW*
N/A
N/A
Outdoor Unit
Comms
enable
ODU=
1 byte, 0 or 1
Command or Query.
Enables or disables communications, via the FSK link, with a Comtech EF Data transceiver (ODU) in the
form x, where:
0=Disabled
1=Enabled
Example: ODU=0 (selects Disabled)
ODU=
ODU?
ODU*
ODU#
ODU?
ODU=x
(see Description of
Arguments)
