CDM-625 Advanced Satellite Modem Revision 13
Introduction MN-CDM625
1–25
EDMAC, EDMAC-2, or EDMAC-3 (NO REED SOLOMON)
Lower Limit (kbps)
Upper Limit (kbps)
No FEC, BPSK
18.0
12295.0
No FEC, O/QPSK
35.5
24590.1
VITERBI, BPSK, 1/2
18.0
6147.5
VITERBI, O/QPSK, 1/2
18.0
12295.0
VITERBI, O/QPSK, 3/4
26.6
18442.6
VITERBI, O/QPSK, 7/8
31.0
21516.3
SEQUENTIAL, BPSK, 1/2
18.0
1024.0
SEQUENTIAL, O/QPSK, 1/2
18.0
2048.0
SEQUENTIAL, O/QPSK, 3/4
26.6
2048.0
SEQUENTIAL, O/QPSK, 7/8
31.0
2048.0
TRELLIS, 8PSK, 2/3
35.5
24590.1
TPC, BPSK, 5/16
18.0
3842.2
TPC, BPSK, 21/44 (aka 1/2)
18.0
5868.1
TPC, O/QPSK, 21/44 (aka 1/2)
18.0
11736.2
TPC, O/QPSK, 3/4
26.6
18442.6
TPC, O/QPSK, 17/18 (aka 0.95)
33.5
23224.0
TPC, O/QPSK, 7/8
31.0
21516.3
TPC, 8PSK/8-QAM, 3/4
39.9
24590.1
TPC, 8PSK/8-QAM, 17/18 (aka 0.95)
50.2
24590.1
TPC, 8PSK/8-QAM, 7/8
46.5
24590.1
TPC, 16-QAM, 3/4
53.2
24590.1
TPC, 16-QAM, 7/8
62.0
24590.1
LDPC, BPSK, 1/2
18.0
6147.5
LDPC, O/QPSK, 1/2
18.0
12295.0
LDPC, O/QPSK, 3/4
26.6
18442.6
LDPC, O/QPSK, 2/3
23.7
16393.4
LDPC, 8PSK/8-QAM, 3/4
39.9
24590.1
LDPC, 8PSK/8-QAM, 2/3
35.5
24590.1
LDPC, 16-QAM, 3/4
53.2
24590.1
EDMAC, EDMAC-2, or EDMAC-3 (ANY REED SOLOMON)
Lower Limit (kbps)
Upper Limit (kbps)
VITERBI, BPSK, 1/2
18.0
5532.7
VITERBI, O/QPSK, 1/2
18.0
11065.5
VITERBI, O/QPSK, 3/4
24.0
16598.3
VITERBI, O/QPSK, 7/8
27.9
19364.7
SEQUENTIAL, BPSK, 1/2
18.0
1024.0
SEQUENTIAL, O/QPSK, 1/2
18.0
2048.0
SEQUENTIAL, O/QPSK, 3/4
24.0
2048.0
SEQUENTIAL, O/QPSK, 7/8
27.9
2048.0
TRELLIS, 8PSK, 2/3
31.9
22131.1
VIT 16-QAM, 3/4
47.9
22131.1
VIT 16-QAM, 7/8
55.8
22131.1
IBS (NO REED SOLOMON)
Lower Limit (kbps)
Upper Limit (kbps)
No FEC, BPSK
64.0
8448.0
No FEC, O/QPSK
64.0
8448.0
