VITERBI, BPSK, 1/2
64.0
5859.3
VITERBI, O/QPSK, 1/2
64.0
8448.0
VITERBI, O/QPSK, 3/4
64.0
8448.0
VITERBI, O/QPSK, 7/8
64.0
8448.0
SEQUENTIAL, BPSK, 1/2
64.0
1024.0
SEQUENTIAL, O/QPSK, 1/2
64.0
2048.0
SEQUENTIAL, O/QPSK, 3/4
64.0
2048.0
SEQUENTIAL, O/QPSK, 7/8
64.0
2048.0
TRELLIS, 8PSK, 2/3
64.0
8448.0
TPC, BPSK, 5/16
64.0
3662.1
TPC, BPSK, 21/44 (aka 1/2)
64.0
5593.0
TPC, O/QPSK, 21/44 (aka 1/2)
64.0
8448.0
TPC, O/QPSK, 3/4
64.0
8448.0
TPC, O/QPSK, 17/18 (aka 0.95)
64.0
8448.0
TPC, O/QPSK, 7/8
64.0
8448.0
TPC, 8PSK/8-QAM, 3/4
64.0
8448.0
TPC, 8PSK/8-QAM, 17/18 (aka 0.95)
64.0
8448.0
TPC, 8PSK/8-QAM, 7/8
64.0
8448.0
TPC, 16-QAM, 3/4
64.0
8448.0
TPC, 16-QAM, 7/8
64.0
8448.0
LDPC, BPSK, 1/2
64.0
5859.3
LDPC,O/ QPSK, 1/2
64.0
8448.0
LDPC, O/QPSK, 3/4
64.0
8448.0
LDPC, O/QPSK, 2/3
64.0
8448.0
LDPC, 8PSK/8-QAM, 3/4
64.0
8448.0
LDPC, 8PSK/8-QAM, 2/3
64.0
8448.0
LDPC, 16-QAM, 3/4
64.0
8448.0
IBS (ANY REED SOLOMON)
Lower Limit (kbps)
Upper Limit (kbps)
VITERBI, BPSK, 1/2
64.0
5208.0
VITERBI, O/QPSK, 1/2
64.0
8448.0
VITERBI, O/QPSK, 3/4
64.0
8448.0
VITERBI, O/QPSK, 7/8
64.0
8448.0
SEQUENTIAL, BPSK, 1/2
64.0
1024.0
SEQUENTIAL, O/QPSK, 1/2
64.0
2048.0
SEQUENTIAL, O/QPSK, 3/4
64.0
2048.0
SEQUENTIAL, O/QPSK, 7/8
64.0
2048.0
TRELLIS, 8PSK, 2/3
64.0
8448.0
VIT 16-QAM, 3/4
64.0
8448.0
VIT 16-QAM, 7/8
64.0
8448.0
ESC++ (NO REED SOLOMON)
Lower Limit (kbps)
Upper Limit (kbps)
No FEC, BPSK
64.0
12304.6
No FEC, O/QPSK
64.0
24609.3
VITERBI, BPSK, 1/2
64.0
5921.0
VITERBI, O/QPSK, 1/2
64.0
12304.6
VITERBI, O/QPSK, 3/4
64.0
18457.0
