CDM-625 Advanced Satellite Modem Revision 13
Introduction MN-CDM625
1–27
VITERBI, O/QPSK, 7/8
64.0
21533.2
SEQUENTIAL, BPSK, 1/2
64.0
1024.0
SEQUENTIAL, O/QPSK, 1/2
64.0
2048.0
SEQUENTIAL, O/QPSK, 3/4
64.0
2048.0
SEQUENTIAL, O/QPSK, 7/8
64.0
2048.0
TRELLIS, 8PSK, 2/3
64.0
24609.3
TPC, BPSK, 5/16
64.0
3700.6
TPC, BPSK, 21/44 (aka 1/2)
64.0
5651.9
TPC, O/QPSK, 21/44 (aka 1/2)
64.0
11745.3
TPC, O/QPSK, 3/4
64.0
18457.0
TPC, O/QPSK, 17/18 (aka 0.95)
64.0
23242.1
TPC, O/QPSK, 7/8
64.0
21533.2
TPC, 8PSK/8-QAM, 3/4
64.0
24609.3
TPC, 8PSK/8-QAM 17/18 (aka 0.95)
64.0
24609.3
TPC, 8PSK/8-QAM, 7/8
64.0
24609.3
TPC, 16-QAM, 3/4
64.0
24609.3
TPC, 16-QAM, 7/8
64.0
24609.3
LDPC, BPSK, 1/2
64.0
5921.0
LDPC, O/QPSK, 1/2
64.0
12304.6
LDPC, O/QPSK, 3/4
64.0
18457.0
LDPC, O/QPSK, 2/3
64.0
16406.2
LDPC, 8PSK/8-QAM, 3/4
64.0
24609.3
LDPC, 8PSK/8-QAM,2/3
64.0
24609.3
LDPC, 16-QAM, 3/4
64.0
24609.3
ESC++ (ANY REED SOLOMON)
Lower Limit (kbps)
Upper Limit (kbps)
VITERBI, BPSK, 1/2
64.0
5263.1
VITERBI, O/QPSK, 1/2
64.0
10937.5
VITERBI, O/QPSK, 3/4
64.0
16406.2
VITERBI, O/QPSK, 7/8
64.0
19140.6
SEQUENTIAL, BPSK, 1/2
64.0
1024.0
SEQUENTIAL, O/QPSK, 1/2
64.0
2048.0
SEQUENTIAL, O/QPSK, 3/4
64.0
2048.0
SEQUENTIAL, O/QPSK, 7/8
64.0
2048.0
TRELLIS, 8PSK, 2/3
64.0
21875.0
VITERBI, 16-QAM, 3/4
64.0
21875.0
VITERBI, 16-QAM, 7/8
64.0
21875.0
VersaFEC (ANY MODE)
Lower Limit (kbps)
Upper Limit (kbps)
VersaFEC BPSK Rate 0.488
18.0
5700.0
VersaFEC QPSK Rate 0.533
20.0
10000.0
VersaFEC QPSK Rate 0.631
23.0
10000.0
VersaFEC QPSK Rate 0.706
26.0
10000.0
VersaFEC QPSK Rate 0.803
28.0
12000.0
VersaFEC 8-QAM Rate 0.576 (ECCM)
32.0
11000.0
VersaFEC 8-QAM Rate 0.642
35.0
12000.0
VersaFEC 8-QAM Rate 0.711
39.0
12000.0
