CDM-625 Advanced Satellite Modem Revision 13
Appendix F MN-CDM625
F–33
• On/Off state for RF Amplifier mode
• On/Off state for Mute mode
• Online state (Online/Offline)
• LNB current
• BUC Tuning Voltage
Press ENTER or CLEAR to return to the previous menu.
F.3.3.3.3.4.3.1.5 ODU: FSK-control  BUC  Advanced-FSK  LPOD
(2LPODs
 Online/Offline LPOD) Information
Info:
Model Amp LNB Mask Misc ()
These read-only screens provide you with the ODU’s current configuration information without
risking inadvertent changes. Use the
◄ ►arrow keys to select Model, AMP, LNB, Mask, or Misc,
and then press ENTER.
For any LPOD Information screen: Once viewed, press ENTER or CLEAR to return to the previous
menu.
ODU: FSK-control  BUC  Advanced-FSK  LPOD (2LPODs 
Online/Offline LPOD)
 Information  Model
PS1032-1375145-K REF BUC V1.2.2
S/N: 101101068 VER: 1.3.1
This screen displays the LPOD model number, the unit serial number and its operating firmware.
ODU: FSK-control  BUC  Advanced-FSK  LPOD (2LPODs 
Online/Offline LPOD)
 Information  Amp
Amp Info: Att=20.00dB Amp=On
Mute=Disabled Att-Offset=00.00dB
This screen displays the RF Amplifier state, RF Mute state, Attenuation, and AUX Mute state.
