CDM-625 Advanced Satellite Modem Revision 13
Appendix F MN-CDM625
F–34
ODU: FSK-control BUC  Advanced-FSK  LPOD (2LPODs 
Online/Offline LPOD)
 Information  LNB
LNB Current: Src=On SwitchBiasTee=Off
Window:30% Alarm=Disabled
This screen displays the LNB Current information.
ODU: FSK-control  BUC  Advanced-FSK  LPOD (2LPODs 
Online/Offline LPOD)
 Information  Mask
Mask: LFRFPwr=Masked ERLD=Masked
FanSpd=Alarm LNBCD=Alarm LNB22V=Alarm
This screen displays the LPOD mask settings.
ODU: FSK-control  BUC  Advanced-FSK  LPOD (2LPODs 
Online/Offline LPOD)
 Information  Misc
Misc: AFR=Enabled Ref-Adjust=087
LowFwdPowerThreshold=00.00
This screen displays the Auto Fault Recovery state, the Internal 10MHz Reference setting, and
the Low Forward Power Threshold setting.
F.3.3.3.3.4.3.1.6 ODU: FSK-control  BUC  Advanced-FSK  LPOD
(2LPODs
 Online/Offline LPOD)  Redun
Redundancy-Switch-Mode=1:1 Red TX+RX
Force-Online=N Online-State=Offline()
Use the
◄ ►arrow keys to select the setting to edit, and then use the ▲▼ arrow keys to edit
that setting:
Selection Setting
Redundancy-Switch-Mode
Off, 1:1 Red Tx, 1:1 Red TX+RX, Manual.
Force-Online
Select
Yes
to force Offline unit to generate a redundant switchover.
Otherwise, select No.
Online-State
Read-only. Displays status as Online or Offline.
Press ENTER when done.
