Enter/Exit Programming Mode 2D Symbology Programming
430 Magellan™ 9300i / 9400i Scanners
PDF 417 Length 1, Length 2 Programming Instructions
If PDF417 Length Control is set to Fixed-Length decoding, this feature specifies
PDF417 first fixed length. If PDF417 Length Control is set to Variable-Length
decoding, this feature specifies the minimum label length.
To set this feature:
1. Scan the ENTER/EXIT Programming Mode bar code.
2. Scan the bar code, Set PDF 417 Length 1 on page 430 or Set PDF 417
Length 2 on page 430 below. You’ll need to cover any unused bar codes
on this and the facing page to ensure that the scanner reads only the bar
code you intend to scan.
3. Scan the appropriate digits from the Keypad on page 461 in Appendix C
that represent the desired label length. The selectable range for this
option is 0001 to 2710. Pad all numbers with leading zeros to yield a four-
digit entry (0001-2710).
4. Complete the programming sequence by scanning the ENTER/EXIT Pro-
gramming Mode bar code.
NOTE
This tag is only valid for units with a model id that sup-
ports PDF.
Length 1 is the minimum label length if in variable
length mode, or the first fixed length if in fixed length
mode. Length 2 is the maximum label length if in vari
-
able length mode, or the second fixed length if in fixed
length mode. Length includes the bar code's data char
-
acters only. Any value > 2710 will be considered to be
2710.
Default setting for this feature = 0001
Set PDF 417 Length 1
Set PDF 417 Length 2
Default setting for this feature = 0A96
