C207 - (DASH SIDE)
CAV CIRCUIT
11 16DG
12 16YL
17 16RD/YL
C207 - (MAIN BODY SIDE)
CAV CIRCUIT
11 16DG
12 16YL
17 16RD/YL
C208 - (CABIN SIDE)
CAV CIRCUIT
316WT
416BK
C208 - (DASH SIDE)
CAV CIRCUIT
316WT
416BK
C209 - (CABIN SIDE)
CAV CIRCUIT
1 16BR/BL
2 16WT/BL
3 16BR/DG
4 16WT/DG
8W - 80 - 20 8W-80 CONNECTOR PIN-OUTS VA
