C209 - (DASH SIDE)
CAV CIRCUIT
1 16BR/BL
2 16WT/BL
3 16BR/GY
4 16WT/GY
C210 - (DRIVER DOOR SIDE)
CAV CIRCUIT
114BR
2 16BK/YL
3 16BK/YL/DG
4 16BK/WT
5 16BL/WT
6-
C210 - BLACK (MAIN BODY SIDE)
CAV CIRCUIT
114BR
2 16BK/YL
3 16BK/YL/DG
4 16BK/WT
5 16BL/WT
6-
C211 - (POWER MIRROR SWITCH SIDE)
CAV CIRCUIT
118BR
2 18BK/RD
3-
4 18BL/DG
518DG
6 18WT/GY
VA 8W-80 CONNECTOR PIN-OUTS 8W - 80 - 21
