C211 - BLACK (POWER MIRROR SIDE)
CAV CIRCUIT
118BR
2 18BK/RD
3-
4 18BL/DG
518DG
6 18WT/GY
C214 - LT. BLUE (CABIN SIDE)
CAV CIRCUIT
116YL
216VT
316BK
416BR
5-
6-
C214 - LT. BLUE (DASH SIDE)
CAV CIRCUIT
116YL
216VT
316BK
416BR
5-
6-
C215 - BLACK (CABIN SIDE)
CAV CIRCUIT
1 16RD/YL
2 16BK/RD
3-
4-
5 16BR/WT
614BR
8W - 80 - 22 8W-80 CONNECTOR PIN-OUTS VA
