C215 - BLACK (MAIN BODY)
CAV CIRCUIT
1 16RD/YL
2 16BK/RD
3-
4-
5 20BR/WT
614BR
C216 - BLACK (CABIN SIDE)
CAV CIRCUIT
112RD
2-
C216 - BLACK (MAIN BODY SIDE)
CAV CIRCUIT
112RD
2-
C217 - (CABIN SIDE)
CAV CIRCUIT
1 16RD/YL
216YL
316DG
416YL
C217 - (MAIN BODY SIDE)
CAV CIRCUIT
1 16RD/YL
216YL
316DG
416YL
VA 8W-80 CONNECTOR PIN-OUTS 8W - 80 - 23
