C218 - (CABIN SIDE)
CAV CIRCUIT
1 16BR/WT
2 16BR/YL
3 16RD/DG
4 16DG/YL
5 20DG/BK
6 20GY/BK
7 20DG/WT/BL
8-
C218 - (MAIN BODY SIDE)
CAV CIRCUIT
1 16BR/WT
2 16BR/YL
3 16RD/DG
4 16DG/YL
5 20DG/BK
6 20GY/BK
7 20DG/WT/BL
C219 - (MAIN BODY SIDE)
CAV CIRCUIT
5 16BK/RD
6 16BL/RD
7 16YL/WT
8 16DG/BK
9 16BK/RD
10 16BL/RD
11 16YL/RD
12 16DG/YL
C219 - BLACK (CABIN SIDE)
CAV CIRCUIT
5 16BK/RD
6 16BL/RD
7 16YL/WT
8 16DG/BK
9 16BK/RD
10 16BL/RD
11 16YL/RD
12 16DG/YL
8W - 80 - 24 8W-80 CONNECTOR PIN-OUTS VA
