C220 - (CIGARETTE SIDE)
CAV CIRCUIT
1 16RD/YL
216BR
3 16GY/DG/RD
C220 - (DASH SIDE)
CAV CIRCUIT
1 16RD/YL
216BR
3 16GY/DG/RD
C221 - (MAIN BODY SIDE)
CAV CIRCUIT
1 16BL/WT
2 16BK/YL/DG
3 16BK/WT
C221 - (PASSENGER DOOR SIDE)
CAV CIRCUIT
1 16BL/WT
2 16BK/YL/DG
3 16BK/WT
C224 - (BLOWER MOTOR/SOLENOID SIDE)
CAV CIRCUIT
112RD
212BK
216BK
VA 8W-80 CONNECTOR PIN-OUTS 8W - 80 - 25
