C224 - (MAIN BODY SIDE)
CAV CIRCUIT
112RD
212BR
C225 - (BLOWER MOTOR/SOLENOID SIDE)
CAV CIRCUIT
112RD
2 12RD/BL
316RD
C225 - (DASH SIDE)
CAV CIRCUIT
1 12RD/BL
212BL
316RD
C226 - (CABIN SIDE)
CAV CIRCUIT
116GY
2-
3 16RD/DG
4 16RD/BL
516BK
616BR
C300 - (BODY SIDE)
CAV CIRCUIT
1 16RD/YL
120RD
220YL
320WT
8W - 80 - 26 8W-80 CONNECTOR PIN-OUTS VA
