DESCRIPTION N·m Ft. Lbs. In. Lbs.
Bolt-Connecting Rod Cap
to Connecting Rod (3
stage, 1&2 torque, 1
torque angle)
5,25,90° - 44,221, 90°
Crankshaft
Bolt-Crankshaft Bearing
Cap (2 stage, 1 torque, 1
torque angle
55,90° 40.5, 90° -
Flywheel, Driven Plate, Vibration Damper, Starter Ring Gear
8.8m-Bolt-Central Bolt of
Vibration Damper (2
stage, 1 torque, 1 torque
angle)
200,90° 147.5, 90° -
10.9m-Bolt-Central Bolt of
Vibration Damper (2
stage, 1 torque, 1 torque
angle)
325,90° 240, 90° -
Bolt-Stretch Shank for
Flywheel or 2 Mass Fly-
wheel to Crankshaft (2
stage, 1 torque, 1 torque
angle)
45,90° 33, 90°
Turbo Charger
Bolt-Oil Feed Line to Cyl-
inder Head
9/22 - 80-194
Bolt-Oil Feed Line to Tur-
bo Charger
30 22 -
Bolt-Turbo Charger Sup-
port
30 22 -
Bolt-Turbo Charger Sup-
port to Crankcase
20 - 177
Bolt-Oil Outlet Line to
Turbo Charger
9 - 80
Connection-Flange of Ex-
haust Manifold to Turbo
Charger
30 22 -
Connection-Turbo Charger
to Front Catalytic Con-
verter
30 22 -
Charge Air Pipe/Charge Air Cooling
Bolt-Charge Air Distribu-
tion Pipe
16 - 141
Bolt-Inlet Port Shut Off
Positioning Motor to Air
Charge Distribution Pipe
9 - 80
Bolt-Support to Charge
Air Distribution Pipe
20 - 177
Bolt-Support to Engine
Bracket
40 30 -
9 - 12 ENGINE VA
