DESCRIPTION N·m Ft. Lbs. In. Lbs.
Oil Filter
Screw Cap to Oil Filter 25 18.5 -
Oil Cooling System
Bolt-Oil-Water Heat Ex-
changer to Timing Cover
Case
15 - 133
Oil Level Pressure
Bolt-Dip Stick Guide Tube
to Cylinder Head
14 - 123
Bolt-Oil Level Sensor to
Oil Pan
14 - 123
Coolant Pre-Heater
Coolant Pre-Heater in En-
gine Block
35 26 -
Engine Cooling General
Bolt-Belt Pulley to Coolant
Pump
8-35 6 - 26 -
Bolt-Coolant Pump to
Timing Case Cover 6m/
8m
14/20 10 - 15 -
Bolt-Thremostat Housing
to Cylinder Head
9 - 80
Coolant Drain Plug to
Crankcase
30 22 -
Engine Suspension, Engine Mount, Engine Bracket
Bolt-Engine Bracket to
Crankcase (2 stage,
torque, torque angle)
20/90° 15, 90° -
Bolt-Engine Mount to En-
gine Bracket
55 40.5 -
Bolt-Front Engine Mount
to Front Axle Carrier
35 26 -
Bolt-Rear Engine Cross
Member to Body
40 30 -
Bolt-Rear Engine Mount
to Rear Engine Cross
Member
35 26 -
Bolt/Nut- Rear Engine
Mount to Transmission
40 26 -
Bolt-Shrowd to Engine
Bracket
10 - 88.5
Nut-Front Engine Mount
to Engine Bracket
65 48 -
Nut-Engine Mount to Ve-
hicle Frame
35 26 -
Fuel Filter
Bolt-Clip to Fuel Filter 8 - 70
9 - 14 ENGINE VA
