DESCRIPTION N·m Ft. Lbs. In. Lbs.
Bolt- Fuel Filter to Charge
Air Distribution Pipe
14 - 124
Exhaust System
Bolt- Catalytic Converter
Bracket to Crankcase
20 - 177
Bolt - Turbocharger Oil
Supply Line at Turbo-
charger
25 18 -
Bolt - Turbocharger Oil
Return Line at Turbo-
charger
10 - 89
Clamp-Connection Be-
tween Front Exhaust Pipe
and Rear Exhaust System
55 41 -
Clip-Front Catalytic Con-
verter to Engine Mount
20 - 177
Exhaust Manifold to Cylin-
der Head
29 21 -
Nut-EGR Valve 9 - 80
Nut-Bracket to Tail Pipe 55 40.5 -
Nut-Exhaust Bracket to
Threaded Plate of Center
Exhaust Pipe
20 - 177
Support-Exhaust Bracket
on Transmission
20 - 177
Refrigerant Compressor
Bolt-Refrigerant Compres-
sor to Timing Case Cover
20 - 177
Bolt-Refrigerant Compres-
sor to Bracket
20 - 177
Bolt-Refrigerant Lines to
Refrigerant Compressor
20 - 177
Timing Chain, Chain Tensioner
Bolt-Camshaft Sprocket to
Exhaust Camshaft
18 - 159
Bolt-Intermediate Gear of
High Pressure Pump to
Cylinder Head
40 29.5 -
Timing Chain Tensioner to
Timing Case Cover
80 59 -
Camshaft
Bolt-Camshaft Bearing
Cap to Cylinder Head
9 - 80
Bolt-Driver to Inlet Cam-
shaft
50 37 -
Common Rail Diesel Injection
Bolt-Banjo Bolt of Leak
Oil Line to Rail
20 - 177
VA ENGINE 9 - 15
