Torque from the tor que con verter is increased via
the input sh aft (25) and a ll thr ee pla neta ry gear sets
and tra nsferred wit h r eversed direction of r otat ion to
the ou tput sha ft (26) (Fig. 14) and (Fig. 15).
Front Planetary Gear Set
The clut ch K1 (7) is shifted. The planetary carr ier
(13) and sun gea r (21) are conn ected to ea ch other as
a resu lt. The annu lus gear (8) is driven via th e input
sh aft (25). The planetary gear set is locked a nd turn s
as a unit.
Rear Planetary Gear Set
The plan etar y ca rrier (15) is held against the hous-
ing by th e enga ged multiple-disc h olding clutch B3
(5). The annu lus gear (11) t urns at a r edu ced speed
du e to the mechanical conn ection to t he front plane-
tary car rier (13). The planetar y pin ion gears (19)
turn between t he a nnulus gear (11) an d the sun gear
(23). The dir ection is rever sed by t he held planetar y
carrier (15) so tha t the su n gear (23) turns in the
opposite direction to the runnin g direct ion of the
en gin e.
Center Planetary Gear Set
The an nulus gear (10) is held aga inst the hou sing
by the multiple-disc holding clu tch B3 (5) via th e
mecha nica l connect ion t o the planetary carr ier (15).
The sun gear (22) tu rns ba ckwa rds due to the
enga ged mu ltiple-disc clutch K3 (12). The planet ary
gear s (18) turn on the fixed a nnulus gear (10) an d
increase the torqu e from t he su n gear (22) to the
planet ary carrier (14). The out pu t shaft (26) con-
nected to th e pla neta ry carrier (14) tu rns at a
reduced speed in the opposite direction to th e r un-
ning direction of the engine.
Fig. 15 Reverse Gear Powerflow - Limp In
1 - TORQUE CONVERTER LOCK-UP CLUTCH 14 - CENTER PLANETARY CARRIER
2 - TORQUE CONVERTER TURBINE 15 - REAR PLANETARY CARRIER
3 - TORQUE CONVERTER IMPELLER 16 - TORQUE CONVERTER STATOR
4 - HOLDING CLUTCH B1 17 - FRONT PLANETARY PINION GEARS
5 - HOLDING CLUTCH B3 18 - CENTER PLANETARY PINION GEARS
6 - HOLDING CLUTCH B2 19 - REAR PLANETARY PINION GEARS
7 - DRIVING CLUTCH K1 20 - FREEWHEELING CLUTCH F1
8 - FRONT PLANETARY ANNULUS GEAR 21 - FRONT PLANETARY SUN GEAR
9 - DRIVING CLUTCH K2 22 - CENTER PLANETARY SUN GEAR
10 - CENTER PLANETARY ANNULUS GEAR 23 - REAR PLANETARY SUN GEAR
11 - REAR PLANETARY ANNULUS GEAR 24 - FREEWHEELING CLUTCH F2
12 - DRIVING CLUTCH K3 25 - INPUT SHAFT
13 - FRONT PLANETARY CARRIER 26 - OUTPUT SHAFT
A - ENGINE SPEED D - SECOND GEAR RATIO
B - TRANSMISSION INPUT SPEED E - FIXED PARTS
C - FIRST GEAR RATIO
VA AUTOMATIC TRANSMISSION NAG1 - SERVICE INFORMATION 21 - 23
