(0.118-0.134 in.) for four disc ver sions, 3.3-3.7 mm
(0.130-0.146 in.) for five disc versions, and 3.6-4.0
mm (0.142-0.158 in.) for six disc versions.
(13) Adjust with snap-rin g (5), if necessar y. Sn ap-
rings a re available in thickn esses of 2.6 mm (0.102
in.), 2.9 mm (0.114 in.), 3.2 mm (0.126 in.), 3.5 mm
(0.138 in.), 3.8 mm (0.150 in.), and 4.1 mm (0.162
in.).
(14) Insert front freewh eeling clu tch F1 (2) and fit
sn ap-ring (3). The freewheelin g clu tch F1 (2) must be
insta lled in the direct ion of th e arr ow.
(15) For tr ansmissions u sing single sided friction
discs, use a feeler gauge t o determ ine the play “L”
(Fig. 87) a t thr ee points bet ween the sna p-r ing (4)
and outer multiple-disc (2).
(16) During th e m easurem ent the sna p-r ing (4)
must con tact t he upper bea ring surfa ce of t he gr oove
in the outer m ultiple-disc carrier (3).
(17) The correct clutch clear ance for t ransmissions
with single sided fr iction discs is 2.4-2.8 mm (0.095-
0.110 in . ) for six frict ion disc versions, 2.6-3.0 m m
(0.102-0.1 18 in.) for eight disc version s, 2.8-3.2 mm
(0.110-0.126 in.) for ten disc versions, an d 2.9-3.3 mm
(0.114-0.130 in .) for twelve disc ver sions.
(18) Adjust with snap-rin g (4), if necessar y. Sn ap-
rings a re available in thickn esses of 2.6 mm (0.102
in.), 2.9 mm (0.114 in.), 3.2 mm (0.126 in.), 3.5 mm
(0.138 in.), 3.8 mm (0.150 in.), and 4.1 mm (0.162
in.).
(19) Insert front freewh eeling clu tch F1 (2) and fit
sn ap-ring (3). The freewheelin g clu tch F1 (2) must be
insta lled in the direct ion of th e arr ow.
Fig. 87 Input Clutch K1 Stack-up - Single Sided
Discs
1 - OUTER MULTIPLE DISCS
2 - OUTER MULTIPLE DISC - 4.0MM (0.158 IN.)
3 - K1 OUTER DISC CARRIER
4 - SNAP-RING
5 - INNER MULTIPLE DISCS
6 - DISC SPRING
7 - PISTON
21 - 96 AUTOMATIC TRANSMISSION NAG1 - SERVICE INFORMATION VA
