Torque Converter Lockup Clutch Regulating Valve
The tor que converter lock-up clutch regulating
valve (6) (Fig. 102) is located in the va lve housing of
the elect rohydraulic con trol module. The valve is
responsible for t he hydraulic contr ol of the torqu e
conver ter lockup clut ch an d dist ribu tion of the lubr i-
cating oil.
Fig. 102 Torque Converter Lockup Clutch Regulating Valve
1 - TORQUE CONVERTER LOCK-UP CLUTCH
2 - TORQUE CONVERTER OUTPUT
3 - TORQUE CONVERTER INPUT
4 - LUBRICATION
5 - TORQUE CONVERTER LOCK-UP SOLENOID
6 - TORQUE CONVERTER LOCK-UP CLUTCH REGULATING
VALVE
7 - OIL COOLER
8 - LINE PRESSURE REGULATING VALVE
9 - OIL PUMP
