(6) In st all all check balls (1, 3, 4) (Fig. 138) and
the centr al strain er (2).
(7) In st all the strain er (1) (Fig. 139) in t he inlet t o
torqu e converter lock-u p control solenoid valve.
(8) Position the sealing plat e (3) onto the valve
body (4) (F ig. 140).
(9) In st all the valve hou sing (2) onto t he va lve
body (4) a nd sealing pla te (3).
(10) Install the shift plate Torx! bolts (1) (Fig.
140). Tighten the bolts to 8 N·m (71 in .lbs.).
(11) In st all lea f spr ing (5) (Fig. 140).
(12) Install the str ainer s (1, 2) for th e modulating
pr essu re a nd shift pr essu re con trol solenoid valves
(Fig. 141) into the valve h ousing.
Fig. 139 Converter Lock-up Solenoid Valve Strainer
Location
1 - CONVERTER LOCK-UP SOLENOID STRAINER
Fig. 140 Shift Plate Components
1 - BOLTS - 29
2 - VALVE HOUSING
3 - SEALING PLATE
4 - VALVE BODY
5 - LEAF SPRING
Fig. 141 Solenoid Valve Strainer Locations
1 - SOLENOID VALVE STRAINERS
