STAT I ON ARY GLASS
TABLE OF CONTENTS
page page
BACKLITE - BULKHEAD TRIM PANEL
REMOVAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . 84
QUARTER WINDOW
REMOVAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . 84
WINDSHIELD
WARNING
WINDSHIELD SAFETY PRECAUTIONS . . . . . 85
REMOVAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . 86
BACK LI T E - BU LK H EAD T RI M
PAN EL
REMOVAL
(1) Position an assistant opposite side of the bulk-
head t rim panel to receive the glass a nd wea therstrip
seal.
(2) St art at an u pper corner a nd sepa rate th e sea l
from the window open ing. Push th e gla ss and seal
outwa rd from t he window opening. Remove the gla ss
and seal.
(3) Remove seal from glass if necessary.
(4) Clean the window open ing.
INSTALLATION
(1) In st all the weat herstrip sea l on t he window
gla ss. Verify t hat th e gla ss is seated in the groove
around the edge of t he seal.
(2) In sert a n installation cord in the wea ther st rip
seal inner groove.
NOTE: Use mineral spirits as a lubricant to aid seal
installation in the window opening.
(3) Position the glass and seal in the trim panel
openin g.
(4) Pull the installation cord outward and force the
seal lip over the panel flan ge arou nd t he edge of the
openin g. (Fig. 1)
(5) Seat the sea l inner lip on the panel flange.
Press against the lip a round the edge of the seal.
NOTE: Remove any mineral spirits with a clean
cloth after glass installation.
(6) Verify tha t t he sea l is sea ted in th e trim panel
openin g.
QU ART ER WI N DOW
REMOVAL
(1) Position an assist ant outside the vehicle to
receive t he glass an d weatherstr ip seal.
(2) St art at a n inside, u pper corner. Sepa rate the
seal fr om the window opening. Push th e gla ss and
seal outward from the window open ing. Remove th e
glas s and s e al.
(3) Clean the window open ing.
INSTALLATION
(1) In st all the weat herstrip sea l on t he window
gla ss. Verify t hat th e gla ss is seated in the groove
around the edge of t he seal.
(2) In sert a n installation cord in the wea ther st rip
seal inner groove.
Fig. 1 Glass & Weatherstrip Seal Installation
1 - BULKHEAD TRIM PANEL
2 - WEATHERSTRIP SEAL
3 - INSTALLATION CORD
4 - TRIM PANEL FRAME
23 - 84 STATIONARY GLASS VA
