Item Description Notes
Low psi Control A/C Pressure
Transducer
Liquid line
mounted -
input to PCM
- operating
range of 200
kPa (29 psi)
to 2799 kPa
(406 psi)
High psi Con-
trol
High Pressure
Relief Valve
Receiver/drier
mounted -
opens at a
discharge
pressure over
3999 kPa
(580 psi)
Refrigerant
Charge Capaci-
ty
Refer to the A/C
Underhood Spec-
ification Label
located in the
engine compart-
ment
R-134a refrig-
erant
A/C Clutch Coil
Draw
2.0-3.7 amps @
12V ± 0.5V @
21° C (70° F)
A/C Clutch Air
Gap
0.5 - 0.88 mm
(0.020 - 0.035
in.)
REAR A/C SY ST EM
Item Description Notes
A/C Compres-
sor
Denso 10S17 ND-8 PAG oil
Freeze-up Con-
trol
Evaporator Tem-
perature Sensor
Input to rear
A/C control
module -
evaporator fin
mounted -
cycles clutch
off below 1.6°
C (35° F),
cycles clutch
back on
above 3.9° C
(39° F)
Low psi Control A/C Low Pres-
sure Switch
Input to rear
A/C control
module - suc-
tion line
mounted -
cycles clutch
off below 30
kPa (4.4 psi)
Item Description Notes
High psi Con-
trol
A/C High Pres-
sure Switch
Input to rear
A/C control
module - con-
denser inlet
tube mounted
- cycles clutch
off above
2551 kPa
(370 psi)
Refrigerant
Charge Capaci-
ty
Refer to the Rear
A/C Specification
Label
R-134a refrig-
erant
A/C Clutch Coil
Draw
3.3 amps @ 12V
± 0.5V @ 21° C
(70° F)
A/C Clutch Air
Gap
0.35 - 0.60 mm
(0.014 - 0.024
in.)
VA HEATING & AIR CONDITIONING 24 - 7
