Dodge Sprinter 2006 - Page 348

Symptom:
IN COR RE CT TON E WH EE L
Wh e n Mo n i to re d a n d S e t Co n d it i o n :
IN COR RE CT TON E WH EE L
Wh en Mon it or ed: Ign it ion On - Con t inu ou sly
Set Con dit ion : Wh en cont in u ou s ABS con t rol is a ct ive for on e min u t e on on e or m ore
wh eels OR in t er fer en ce on one or m ore wh eels OR devia t ion of t wo wh eel speeds at eit her
side of veh icle by 6 km /h (4 m ph ) or a t t he fr on t a xle by 10 km /h (7 mph ). If a t lea st one
wh eel is 5 km /h (3 mph ) or less, a wh eel speed devia tion of a djoin in g wh eels of 12 km /h (8
mph ) is a llowed.
POSSIBLE CAUSES
INTERMITTENT INCORRECT TONE WHE EL DTC
IN CORRECT TIRE S ON VE H ICLE
TIRE CIRCU MF E RE NCE S N OT MATCH IN G
WH E EL SP E E D SE NSOR CIRCU IT SH ORT TO VOLTAGE
INCORRECT TONE WH EEL
WHEEL S PEED S ENS O R CI RC U I T S HOR T TO GR OUND
DAMAGE D WH E EL BE ARIN G
WHEEL S PEED S ENS O R CI RC U I T O P EN
DAMAGE D BRAKE LININGS/COMP ONE NTS
WHEEL S PEED S ENS O R CI RC U I T S S HOR TED TO GET HER
WHEEL S PEED S ENS O R
TE S T ACTION AP PLICAB ILITY
1 Tur n th e ign it ion on .
Wit h th e DRBIII",readDTCs.
Wit h th e DRBIII",eraseDTCs.
Tur n th e ign it ion off.
Tur n th e ign it ion on .
Roa d t est th e veh icle.
Du r ing t h e r oa d t est , drive t h e veh icle a bove 100 km /h (62 m ph ) for at lea st 3 min u t es
an d per for m sever a l st ops a n d An t ilock stops.
St op t h e v eh icle.
Wit h th e DRBIII",readDTCs.
Does t h e DRBIII" display INCORRECT TONE WHE EL?
All
Ye s → Go To 2
No → Go To 13
32
BRAK ES (CAB)
