TE S T ACTION AP PLICAB ILITY
2 Tur n th e ign it ion off.
In spect t h e t ir e sizes on th e veh icle.
Is a sm a ller th a n pr odu ction tir e or spa r e t ir e bein g u sed?
All
Ye s → Repa ir a s n ecessa ry.
Per for m ABS VE RIF ICATION TE ST - VER 1.
No → Go To 3
3 Tur n th e ign it ion off.
Mea su r e all th e tir e cir cu m feren ces.
Do all t h e tir e cir cu mfer en ces m a t ch ?
All
Ye s → Go To 4
No → Repa ir as n ecessa r y.
Per for m ABS VE RIF ICATION TE ST - VER 1.
4 Tur n th e ign it ion off.
In spect t h e t on e wheel(s) for da ma ge, missin g t eet h , cr a cks, or loosen ess.
NOTE: Re fe r t o t h e s e rv ic e m an u a l in fo rm at io n , if n e c e s s a ry, fo r pro c e d u re s
or specifications.
Are on e or m or e ton e wh eel(s) loose or da ma ged?
All
Ye s → Repa ir a s n ecessa ry.
Per for m ABS VE RIF ICATION TE ST - VER 1.
No → Go To 5
5 Tur n th e ign it ion off.
In spect t h e wh eel bea r in gs for excessive ru n ou t or clea r a n ce.
NOTE: R e fe r to th e s e rv ic e i n fo rm a ti o n , if n e c e ss a ry, fo r p ro c e d u re s o r
specifications.
Is t h e wh eel bea r in g clea r an ce wit h in specifica t ion s?
All
Ye s → Go To 6
No → Repa ir as n ecessa r y.
Per for m ABS VE RIF ICATION TE ST - VER 1.
6 Tur n th e ign it ion off.
Visu a lly inspect t h e br a kes for lockin g u p du e t o lin in g con t a m ina t ion or over hea t in g.
In spect a ll br a ke compon en t s for a n y con dit ion t h a t wou ld ca u se a va r ia t ion in wh eel
speed.
Is a n y com pon ent da ma ged?
All
Ye s → Repa ir a s n ecessa ry.
Per for m ABS VE RIF ICATION TE ST - VER 1.
No → Go To 7
7 Tur n th e ign it ion on .
Wit h t h e DRBIII" in Sen sor s, m on it or ALL th e Wheel Speed Sen sor sign a ls wh ile an
assist a n t dr ives t h e veh icle.
Slowly a cceler a t e from a st op t o 65 km /h (40 mph ).
NOTE: Wheel Speed should not vary by more than 10%from wheel to wheel
when driving in a straight line.
Do a n y of t h e Wh eel Speed Sen sor sign a ls va r y by gr ea t er th a n 10% wh ile dr ivin g in
astraightline?
All
Ye s → Go To 8
No → Go To 13
33
BRAK ES (CAB)
IN COR RE CT TON E WH EE L — Co nt in ued
