Symptom List:
LE F T F RON T IN LE T S OLE N OID
LE F T F RON T OU TLE T S OLE N OID
LE F T F RON T, R IGHT R EAR IN LE T S OLE N OID
LE F T F RON T, R IGHT R EAR OU TLE T S OLE N OID
LE F T RE AR IN LE T S OLE N OID
LE F T RE AR OU TLE T S OLE N OID
RIGHT FRONT INLET SOLENOID
RIGHT FRONT OUTLET SOLENOID
RIGHT FRONT, LEFT REAR INLET SOLENOID
RIGHT FRONT, LEFT REAR OUTLET SOLENOID
RIGHT REAR INLET SOLENOID
RIGHT REAR OUTLET SOLENOID
Te s t N o t e : Al l s y m p t o m s l i s t e d a b o v e a r e d i a g n o s e d u s i n g t h e s a m e t e s t s .
Th e ti tle fo r the t e s t s w ill b e LEF T F R ON T IN LE T S OLE -
NOID.
Wh e n Mo n i to re d a n d S e t Co n d it i o n :
LE F T F R ON T IN LE T S OLE N OID
Wh en Mon it or ed: Ign it ion On - Con t inu ou sy
Set Con dit ion : Wh en t h e elect r ica l feedba ck sign a l does n ot ma tch th e a ct ua t ion signa l
for th e solen oid OR du rin g th e solen oid a nd pu m p mot or t est wh en a ll solen oids a r e t est ed
in series an d a solen oid r espon se sign a l is det ect ed.
POSSIBLE CAUSES
INTERMITTENT SOLENOID DTC
DAMAGE D CAB/CAB HARN E SS CONNE CTOR
FUSE D OPTIONAL E QU IP ME NT RE LAY OUTP U T CIRCU IT OP EN
FUSE D B(+) CIRCUIT OP EN
GROU ND CI RCUI T OP E N
ANTI-LOCK BRAKE CONTROLLE R
40
BRAK ES (CAB)
