TE S T ACTION AP PLICAB ILITY
1 NOTE: If a system undervoltage or overvoltage DTC is set along with this
DTC, diagnose the system voltage DTC first.
Tur n th e ign it ion on .
Wit h th e DRBIII",readDTCs.
Wit h th e DRBIII",eraseDTCs.
Tur n th e ign it ion off.
Tur n th e ign it ion on .
Star t t he engine.
Dr ive th e veh icle over 15 km /h (10 mph ) t o t est solen oid a n d pu m p cir cu it s.
St op t h e v eh icle.
Wit h th e DRBIII",readDTCs.
Does t h e DRBIII" display a ny SOLENOID DTCs?
All
Ye s → Go To 2
No → Go To 6
2 Tur n th e ign it ion off.
Discon n ect t he CAB ha r n ess con n ect or.
In spect t h e CAB/CAB ha r n ess con n ect or for da m a ge.
Is t h er e an y br oken , ben t , pu sh ed ou t , corr oded or sprea d t er m in a ls?
All
Ye s → Repa ir a s n ecessa ry.
Per for m ABS VE RIF ICATION TE ST - VER 1.
No → Go To 3
3 Tur n th e ign it ion off.
Discon n ect t he CAB ha r n ess con n ect or.
Tur n th e ign it ion on .
Usin g a 12-volt test ligh t conn ect ed t o gr ou n d, ch eck t h e F u sed Opt ion a l E qu ipm en t
Rela y Ou t pu t cir cu it a t th e CAB ha r n ess con n ect or.
NOTE: Th e t e s t lig h t m u s t illu m in a t e b rig h tly. Co m p are th e brig h tn e ss to
th a t of a dire c t co n n e cti o n to th e ba tte ry.
Does t h e test ligh t illu min a t e br igh t ly?
All
Ye s → Go To 4
No → Repa ir th e F u sed Opt ion a l E qu ipm en t Relay Ou t pu t cir cu it for a n
open .
Per for m ABS VE RIF ICATION TE ST - VER 1.
4 Tur n th e ign it ion off.
Discon n ect t he CAB ha r n ess con n ect or.
Usin g a 12-volt t est ligh t conn ected to gr ou n d, check bot h F used B(+) circu it s a t t h e
CAB h a r n ess con n ect or.
NOTE: Th e t e s t lig h t m u s t illu m in a t e b rig h tly. Co m p are th e brig h tn e ss to
th a t of a dire c t co n n e cti o n to th e ba tte ry.
Does t h e test ligh t illu min a t e br igh t ly?
All
Ye s → Go To 5
No → Repa ir th e F u sed B(+) cir cuit for an open .
Per for m ABS VE RIF ICATION TE ST - VER 1.
41
BRAK ES (CAB)
LE F T F RON T IN LE T S OLE N OID — Co n t in ued
