TE S T ACTION AP PLICAB ILITY
13 Tur n th e ign it ion off.
Discon n ect t he APP Sen sor h a r n ess con n ect or.
Discon n ect t he E CM ha r n ess con n ect or s.
Rem ove t h e E ngin e Con t r ol Rela y.
Con n ect a ju mper wir e bet ween ca vit y 30 a n d ca vit y 87 of t h e En gin e Con t r ol Rela y
conn ect or.
Tur n th e ign it ion on .
Mea su r e th e volt a ge of th e AP P Sen sor Sign a l cir cu it.
Is t h e volt a ge above 1.0 volt ?
All
Ye s → Repa ir t h e AP P Sen sor Sign a l cir cu it for a sh ort t o volt a ge.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Repla ce an d pr ogr a m t h e E ngin e Con t r ol Modu le in a ccor da n ce
wit h th e Ser vice In for m a t ion .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
14 Tur n th e ign it ion off.
Discon n ect t he APP Sen sor h a r n ess con n ect or.
Discon n ect t he E CM ha r n ess con n ect or s.
Mea su r e t h e r esist a n ce of t h e Acceler a t or Peda l Posit ion Sen sor 5-volt Su pply circu it.
Is t h e resista n ce below 10.0 ohm s?
All
Ye s → Go To 15
No → Repa ir t h e Acceler a t or P eda l Posit ion Sen sor 5-Volt Su pply cir cu it
for an open .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
15 Tur n th e ign it ion off.
Discon n ect t he APP Sen sor h a r n ess con n ect or.
Discon n ect t he E CM ha r n ess con n ect or s.
Mea su r e th e r esista n ce bet ween t h e Acceler a t or P eda l P osit ion Sen sor 5-Volt Su pply
cir cu it an d bot h Sen sor Gr ou n d cir cu it s in th e AP P Sensor h ar n ess con n ector.
Is t h e resista n ce a bove 1000 ohm s?
All
Ye s → Go To 16
No → Repa ir t h e 5-Volt Su pply cir cu it for a sh or t t o th e Sen sor Gr ou nd
cir cu it .
Per for m ROAD TE ST VE RIF ICATION - VER-2.
16 Tur n th e ign it ion off.
Discon n ect t he APP Sen sor h a r n ess con n ect or.
Discon n ect t he E CM ha r n ess con n ect or s.
Mea su r e t h e r esist an ce bet ween grou n d a nd t h e Acceler a tor P eda l P osit ion Sen sor
5-volt Su pply cir cu it .
Is t h e resista n ce below 1000 ohm s?
All
Ye s → Repa ir th e Acceler a t or P eda l P osit ion Sen sor 5-Volt Su pply cir cu it
for a sh or t to grou n d.
Per for m ROAD TE ST VE RIF ICATION - VER-2.
No → Go To 17
77
DRI V EABI LI T Y - DI ESEL
P 1222-ACC P EDAL P OS ITION SENS OR 1 CKT P LAU SIB ILITY — Co n t in ued
